SPD Idler Roller for Belt Conveyor, Gravity Roller, Steel Roller Discripton :
About our factory
SPD famous Conveyor Roller brand, 301 - 500 workers, 25000 m³non-dust workshop, Registered Capital: RMB 69,000,000, 20years experience, 35 Engineers and technicians , 28 Professional designers, 7 Senior engineers,18 engineers, two hours to Qingdao port.
Samples are acceptable. Rush order and large quantity are acceptable.
SPD Products details:
SPD Conveyor Roller, Steel Roller, Conveyor Idler details:
The SPD range of conveyor rollers includes both steel and HDPE carry and return rollers. Also available are rubber disc impact and return rollers. Our rollers are fitted with quality ball bearings for maximum life. Belt Widths stocked of our SPD rollers range from 350-1500 are ex stock line items . Larger sizes available on request.
SPD Idler Roller for Belt Conveyor, Gravity Roller, Steel Roller Components & Installation at the Customers' Site Details:
SPD Wood Chips Belt Conveyor Projects Installation on the Sites
Customer Visit & SPD Conveyor Roller Certificate
SPD Idler Roller for Belt Conveyor, Gravity Roller, Steel Roller details:
1. Brand: SPD
2, Lift time: 30000-50000hours
3, Production capacity: as usual 600pieces/day.
4. Roller Diameter: 76-219mm.
5. Roller Length: 190mm to 3500mm.
6. Roller tube: Q235 carbon steel,high-precision ERW, welded with DIN2394 Standard.
7. Shaft: Q235 Carbon Steel in accordance with DIN17100 and other equivalent standard, ISO h6 precision.
8. Bearing: Deep groove ball bearing 2RZ and 2Z with C3 clearance.
9. Bearing brand: SKF,FAG,NSK,LYC etc.
10. Seals: Grease retaining inner seal with multi-stage labyrinthand retention cap with outboard rubbing flinger seal.
11. Color: according to your requirement.
12. Finish: Ordinary painting/Rubber/Steel screw/Galvanized.
13. Welding: Mixed gas shielded arc welding end .
14. Professional designing and inspection team.
15. Standard: CEMA/Australia/ISO/JIS/DIN.
16. Package:Export standard plywood cases with waterproofing film.
|Standard Diameter||Length scope ( mm)||Bearings Type|
|Idler's Shell Wall Thickness|
|89||3 1/3||150~3500||204 205||3.0mm~4.0mm|
|102||4||150~3500||204 205 305||3.5mm~4.0mm|
|108||4 1/4||150~3500||204 205 305 306||3.5mm~4.0mm|
|114||4 1/2||150~3500||205 206 305 306||3.5mm~4.5mm|
|127||5||150~3500||204 205 305 306||3.5mm~4.5mm|
|133||5 1/4||150~3500||205 206 207 305 306||3.5mm~4.5mm|
|140||5 1/2||150~3500||205 206 207 305 306||3.5mm~4.5mm|
|152||6||150~3500||205 206 207 305 306 307 308||4.0mm~4.5mm|
|159||6 1/4||150~3500||205 206 207 305 306 307 308||4.0mm~4.5mm|
|165||6 1/2||150~3500||207 305 306 307 308||4.5mm~6.0mm|
|177.8||7||150~3500||207 306 307 308 309||4.5mm~6.0mm|
|190.7||7 1/2||150~3500||207 306 307 308 309||4.5mm~6.0mm|
|194||7 5/8||150~3500||207 307 308 309 310||4.5mm~6.0mm|
|219||8 5/8||150~3500||308 309 310||4.5mm~6.0mm|
Main Features of SPD Idler Roller for Belt Conveyor, Gravity Roller, Steel Roller
- The bearing housing and steel tube are assembled and welded with a concentric automatic, welding machine.
- Cuting of the steel tube and bearing is performed with the use of a digital aute device/machine/equipment.
- Fabrication of the roller is effected by an auto device and 100% tested for its concentricity.
- Roller and supporting components/materials are manufactured to ISO/BS/JIS/DIN//CEMA/Australia etc. standard.
About Rizhao Port Machine Engineering Co., Ltd
RZPMC is a comprehensive enterprise which engages in design, manufacture, installation and maintenance of the bulk-handling equipments. It is the wholly-owned subsidiary of the listed governmental company Rizhao port Co., Ltd.
We begin to make belt conveyor from the year 1993, and has lots of large contracts of manufactures and installation projects,widely used in ports, mining, food, power plants and other industries.
Our steel structures and frames production capacity is 160, 000 tons/year, the main products are belt conveyor, stacker-reclaimer machine, car loader machine, un-loader machine, etc.In the year of 2005, we rely on our own technological superiority, self-design and manufacture the storage capacity of 9000 T/H of the stocker, as a national origination. It has the Second-level Qualification of the Machinery&Electrical Equipments installation Enterprise.
Main Facilities & Capabilities
numberical control cutter machine, semi- manual cutter machines.
300T friction punching machine, 160T punching machine, mechanical plate shearing machine.
Plate roll equipment:
hydraulic four rolles plate roll equipment, mechanical three rolles plate roll equipment.
union melt welding, argon arc welding machine, carbon dioxide protection welding machine, AC arc welding machine, direct current arc welding machine.
Test and MeasureInstruments: PaintFilmThickness Gauge, Buluowei hardness machine, Theodolite Magnetic Particle Flaw Detector, Metal gage, Ultrasonic Flaw Detector.
electric furnace, carburizing furnace.
paint shop facilities:
pneumatic paint shop facility, high- pressure paint shop facility.
Packing and Shipping:
|Application||Coal mining industry, cement, steel, harbour etc.|
|Place of Origin||Rizhao City , Shandong Province , China|
|Material Feature||Water, Wear, Dust resistance|
|Management system||ISO 9001:2008,ISO 14001:2004,GB/T 28001-2001|
