1000kg Electric Roller Conveyor Scissor Lift Table

Heavy duty design.
With safety guard.
With anti-explosion valve.
Customs' special requirements are acceptable.
HW series lift tables meet EN norm and ANSI/ASME safety standards.
These models can be used in above-floor or in-floor pit applications.

Standard Safety Features
Upper platform lifted with aluminum safety bar preventing descent on contact with obstructions.
Low-tention(24V) control box with up-down buttons.
Internal power pack equipped with relief valve against overloading and compensated flow valve for controlled lowering speed.
Heavy duty cylinders with drainage system and check valve to stop the lift table lowering in case of hose burst.
Safety clearance between scissors to prevent trapping during operation.

Other Standard Features
Self lubricating bushings on pivot points.
Removable lifting eye to facilitable handling and lift table installation.

ModelCapacityLowered HeightRaised HeightPlatform SizeBase Frame SizeLift Time Power packNet Weight
 kg(mm)(mm)(mm)(mm)(second) (kg)
HW100110002051000820×1300640×124020-25380v/50HZ,AC1.1kw160
HW100220510001000×1600640×124020-25186
HW10032401300850×1700640×158030-35200
HW100424013001000×1700640×158030-35210
HW10052401300850×2000640×158030-35212
HW100624013001000×2000640×158030-35223
HW200120002301050850×1300785×122020-25380v/50HZ,AC1.5kw235
HW200223010501000×1600785×122020-25268
HW20032501300850×1700785×160025-35289
HW200425013001000×1700785×160025-35300
HW20052501300850×2000785×160025-35300
HW200625013001000×2000785×160025-35315
HW4001400024011001200×1700900×160030-40380v/50HZ,AC2.2kw375
HW400224011001200×2000900×160030-40405
HW400330014001000×2000900×200045-50470
HW400430014001200×2000900×200045-50490
HW400530014001000×2200900×200045-50480
HW400630014001200×2200900×200045-50505
HW400730014001500×17001200×160045-50420
HW400830014001800×22001500×200045-50540

1000kg Electric Roller Conveyor Scissor Lift Table



Electric Lift Table with Protection Skirt and Wheels:

1000kg Electric Roller Conveyor Scissor Lift Table

Electric Lift Table with Ball Table:
1000kg Electric Roller Conveyor Scissor Lift Table


1000kg Electric Roller Conveyor Scissor Lift Table


FAQ:

Q: What about the quality of the products?
A: Our products are CE approved, and we have five inspection steps before shipment:
1. Inspect the raw material in accordance with ISO9001;
2. Strict inspection in the whole production process;
3. Load limit test when assembling finished;
4. 100% strict inspection of products before shipment;
5. If needed, inspection by buyer.

Q: How long is the quality guarantee?
A: All of our products carry one-year warranty.

Q: What's the leadtime?
A: Normally 30 days.
If you order more than 5 itmes mixed in one container, it will be 45 days.
If you order one item in one container, it will be 20 days.
